65-80R

$0.00

The 65-80R is a metal, retro-fit fire collar for concrete floor slabs, and fire-rated plasterboard, concrete and masonry walls.

For use with a range of pipe types and diameters (See below: click on a Report No. to access PDF).

N.B. All Fire Resistance Levels (FRLs) achieved on framed plasterboard wall systems are applicable to concrete or masonry walls of equal or greater thickness (AS1530.4: 2014 Section 10.12.2 (c)).

Click Here for Installation Instructions

Click Here for Drawing

Click Here for Recommended Fixings Guide

Clear
SKU: N/A Categories: ,

Documentation

Stack ApplicationsDia.FRLReport No.
150mm+ Concrete Slab
PVC Pipe65, 80-/240/240FP4837
- w Fitting Inside Collar ††65, 80-/240/180FAR3933
HDPE Pipe ††63, 75- /240/180FAR3933
Wall ApplicationsDia.FRLReport No.
128mm Plasterboard Wall *
PVC Pipe80-/180/120FP4874
PVC Pipe65, 90-/180/120FAR3929
- w Fitting Inside Collar65, 80-/180/120FAR3929
HDPE Pipe75, 90-/180/120FAR3929
Rehau Raupiano Pipe75-/180/120FC10394
116mm+ Plasterboard Wall **
PVC Pipe80-/120/120FSP2090
- w Fitting Inside Collar65-/120/120FSP1902
96mm+ Plasterboard Wall ***
PVC Pipe90-/90/60FC10395
PVC Pipe80-/90/60FP5663
PVC Pipe65-/90/60FC10395
HDPE Pipe75-/90/60FC10395
FireCrunch MgO Board Wall
PVC Pipe65, 80, 90-/90/90FCO3268
- w Fitting Inside Collar65, 80-/90/90FCO3268
HDPE Pipe75, 90-/90/90FCO3268
Rehau Raupiano Pipe75, 90-/90/90FCO3268

* 2 x 16mm Fire-Rated Plasterboard Sheets Either Side of a 64mm Steel Stud

** 2 x 13mm Fire-Rated Plasterboard Sheets Either Side of a 64mm Steel Stud. For Systems Approved on a 2 x 13mm Fire-rated Plasterboard Sheets One Side of 64mm Steel Stud and 25mm Shaft Liner on the Other, Refer to FCO3348

*** 1 x 16mm Fire-Rated Plasterboard Sheets Either Side of a 64mm Steel Stud

1 x 10mm Firecrunch MgO Board Either Side of 90mm Steel Stud. Contact Manufacturer for Wall System Details

If the Slab Thickness is Increased to 180mm the FRL Increases to -/240/240

Tested in Accordance with AS1530.4 & AS4072.1

NCC Compliant for the Above Uses

Print Friendly, PDF & Email

Product Specs

Element

, , , , , , ,

Cast-in or Retrofit

Application

,

Pipe Type

, ,
